Sweeper Bucket D

The sweeper bucket M3 series D is designed for customers who work both in the field of cable or phone laying sectors and of road maintenance.
It can be fitted to any kind of skid loader, backhoe loader, wheel loader, and forklift up to 7 T; and tractors. It is equipped with hydraulically driven collecting bucket – polypropylene brush Ø 590 mm., no. 2 support wheels 250×50 mm, hydraulic hoses, floating system and mechanical adjustment of the work angle.

Technical specifications

MODELBS 135 DBS 150 DBS 180 DBS 200 DBS 230 DBS 260 D
Width (A)168018302130233026302930
Depth (B)165016501650165016501650
Height (C)120012001200120012001200
Working width [mm]135015001800200023002600
Working width with 20° angle [mm]127014101690188021602440
Required oil flow (at 160bar) [L/min]303030404050
Ø Brush [mm]590590590590590590
Weight with collecting bucket [kg]329344373398429462
Collection bucket capacity [L]166184220244280315
Number of rings [n°]252834384450
